Type |
Type |
Digital, single-lens
reflex, AF / AE camera |
Recording
Media |
CF card (Type I, UDMA
mode 7-compatible), SD memory card, SDHC memory card, SDXC memory card |
sensor size |
Approx. 36 x 24mm |
Compatible
Lenses |
Canon EF lenses
(except EF-S lenses) |
(35
mm-equivalent lens focal length will be as indicated on the lens) |
Lens
Mount |
Canon EF mount |
Sensor |
Type |
CMOS sensor |
Effective
Pixels |
Approx. 22.30
megapixels |
Aspect
Ratio |
3:02 |
Dust
Delete Feature |
Auto, Manual, Dust
Delete Data appending |
Recording
System |
Recording
Format |
Design rule for Camera
File System 2.0 |
Type |
JPEG, RAW (14-bit
Canon original), RAW + JPEG simultaneous recording enabled |
Recording
function |
Standard, Auto switch
card, Rec. separately, Rec. to multiple |
Create /
Select a Folder |
Possible |
File
name |
Preset code, User
setting 1, User setting 2 |
File
numbering |
Continuous, auto
reset, manual reset |
Processing During Shooting |
Style |
Auto, Standard,
Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1 - 3 |
Noise
Reduction |
Applicable to long
exposures and high ISO speed shots |
Automatic
Image Brightness Correction |
Auto Lighting
Optimizer |
Lens
Peripheral Illumination Correction |
Peripheral
illumination correction, Chromatic aberration correction |
Viewfinder |
Type |
Eye-level pentaprism |
Coverage |
Vertical / Horizontal
Approx. 100% (with Eye point Approx. 21mm) |
Magnification |
Approx. 0.71x (-1m-1 with 50mm lens at
infinity) |
Eyepoint |
Approx. 21mm (from
eyepiece lens center at -1m-1) |
Build-in
Dioptric adjustment |
Approx. -3.0 - +1.0m-1 (dpt) |
Focusing
Screen |
Fixed |
Autofocus |
Type |
TTL secondary
image-registration, phase detection |
AF
Points |
61 points (Up to 41
cross-type points) |
*
Number of available AF points and cross-type points vary depending on the
lens. |
Focusing
Brightness Range |
EV -2 - 18 (with
center f/2.8 AF point, 23°C / 73°F, ISO 100) |
Focusing
Modes |
One-Shot AF, AI Servo
AF, AI Focus AF, Manual focusing (MF) |
Exposure
Control |
Metering Modes |
63-zone TTL
full-aperture metering |
•
Evaluative metering (linked to all AF points) |
•
Partial metering (Approx. 6.2% of viewfinder at center) |
•
Spot metering (Approx. 1.5% of viewfinder at center) |
•
Center-weighted average metering |
Metering
Range |
EV 1 - 20 (at 23°C /
73°F with EF50mm f/1.4 USM lens, ISO 100) |
Exposure
Control |
Program AE (Scene
Intelligent Auto, Program), Shutter-priority AE, Aperture-priority AE, Manual
exposure, Bulb exposure |
ISO
Speed (Recommended exposure index) |
Scene Intelligent
Auto: ISO 100 - 12800 set automatically P, Tv, Av, M, B: Auto ISO, ISO 100 -
25600 (in 1/3- or whole-stop increments), or ISO expansion to L (50), H1
(equivalent to ISO 51200), H2 (equivalent to ISO 102400) |
ISO
Speed Settings |
ISO speed range, Auto
ISO range, and Auto ISO minimum shutter speed settable |
HDR
Shooting |
Dynamic
Range Adjustment |
Auto, ±1 EV, ±2 EV, ±3
EV |
Effect |
Natural, Art standard,
Art vivid, Art bold, Art embossed |
Auto
Image Align |
Possible |
Multiple
Exposures |
Shooting
Method |
Function / control
priority, Continuous shooting priority |
No. of
Multiple Exposures |
2 to 9 exposures |
Multiple-Exposure
Control |
Additive, Average,
Bright, Dark |
Shutter |
Type |
Electronically-controlled,
focal-plane shutter |
Shutter Speeds |
1/8000sec. to 1/60sec.
(Scene Intelligent Auto mode), X-sync at 1/200sec. |
*
With a wide-angle lens, the shutter speed may be 1/60sec. or slower. |
1/8000sec. to 30secs., bulb (Total shutter speed range.
Available range varies by shooting mode.) |
Drive
System |
Drive
Modes |
Single shooting,
High-speed continuous shooting, Low-speed continuous shooting, Silent single
shooting, Silent continuous shooting, 10secs. self-timer / remote control,
2secs. self-timer / remote control |
Live
View Shooting |
Shooting
Modes |
3:2, 4:3, 16:9, 1:1 |
Focusing
Modes |
Live mode, Face
detection Live mode (contrast detection), Quick mode (phase-difference
detection), Manual focusing (Approx. 5x / 10x magnification possible) |
Focusing
brightness range |
EV 1 - 18 (with
contrast detection, at 23°C / 73°F, ISO 100) |
Metering
Modes |
Evaluative metering
with the image sensor |
Metering
Range |
EV 0 - 20 (at 23°C /
73°F with EF50mm f/1.4 USM lens, ISO 100) |
Silent
Shooting |
Provided (Mode 1 and
2) |
Three
Types |
Three types |
Movie
Shooting |
Movie
Recording Compression |
MPEG-4 AVC / H.264 |
Variable
(average) bit rate |
Audio
Recording Format |
Linear PCM |
Recording
Format |
MOV |
Focus
Modes |
Same as focusing with
Live View shooting |
Metering
Modes |
Center-weighted
average and Evaluative metering with the image sensor |
*
Automatically set by the focusing mode. |
Metering
Range |
EV 0 - 20 (at 23°C /
73°F with EF50mm f/1.4 USM lens, ISO 100) |
Exposure Control |
1. Autoexposure, |
2.
Shutter-priority AE, |
3.
Aperture-priority AE, |
4.
Manual exposure |
*
With 1, 2, and 3, exposure compensation and AE lock are possible (except in
Scene Intelligent Auto mode). |
Exposure
compensation |
±3 stops in 1/3-stop
increments (±5 stops for still photos) |
ISO
speed |
Scene Intelligent Auto
and Tv: Automatically set within ISO 100 - 12800 |
Sound
Recording |
Built-in monaural
microphone, external stereo microphone terminal provided |
Sound
recording level adjustable, wind filter provided |
Headphones |
Headphone terminal
provided |
Grid
Display |
Three types |
Still
Photos |
Possible |
LCD
Monitor |
Type |
TFT colour,
liquid-crystal monitor |
Monitor
Size and Dots |
Wide, 8.1 cm (3.2-in.)
(3:2) with Approx. 1.04 million dots |
Brightness
Adjustment |
Auto (Dark, Standard,
Bright), Manual (7 levels) |
Playback |
Display Formats |
Single image display,
Single image + Info display (Basic info, shooting info, histogram), 4-image
index, 9-image index, 2-image display |
Highlight
Alert |
Overexposed highlights
blink |
Grid
Display |
Three types |
Zoom
Magnification |
Approx. 1.5x - 10x,
starting magnification and position settable |
Browsing Methods |
Single image, jump by
10 or 100 images, by shooting date, by folder, by movies, by stills, by
rating |
Rotate |
Possible |
Movie
Playback |
Enabled (LCD monitor,
video / audio OUT, HDMI OUT), built-in speaker |
Slide
Show |
All images, by date,
by folder, movies, stills, or by rating |
Direct
Printing |
Compatible
Printers |
PictBridge-compatible
printers |
Printable
Images |
JPEG and RAW images |
Print
Ordering |
DPOF Version 1.1
compatible |
Transfer |
Transferrable
Images |
Still photos (JPEG,
RAW, RAW + JPEG images), Movies |
Custom
Functions |
Custom
Functions |
13 |
My Menu
Registration |
Possible |
Custom
Shooting Modes |
Register under Mode
Dial's C1 / C2 / C3 |
Copyright
Information |
Entry and inclusion
enabled |
Interface |
Audio
/ Video OUT/ Digital Terminal |
Analog video
(Compatible with NTSC / PAL) / stereo audio output |
Personal
computer communication, Direct printing (Hi-Speed USB or equivalent),
Wireless File Transmitter WFT-E7, GPS Receiver GP-E2 connection |
HDMI
mini OUT terminal |
Type C (Auto switching
of resolution), CEC-compatible |
External
Microphone IN Terminal |
3.5mm stereo mini-jack |
Headphone
terminal |
3.5mm stereo mini-jack |
Remote
Control Terminal |
Compatible with
N3-type remote controller |
Wireless
Remote Control |
Remote Controller RC-6 |
Eye-Fi
card |
Compatible |
Power |
Battery |
Battery Pack LP-E6
(Quantity 1) |
*
AC power can be supplied via AC Adapter Kit ACK-E6. |
*
With Battery Grip BG-E11 attached, size-AA/LR6 batteries can be used. |
Battery
Information |
Remaining capacity,
Shutter count, Recharge performance, and Battery registration possible |
Battery
Life (Based on CIPA testing standards) |
With viewfinder shooting: |
Approx. 950 shots at 23°C /
73°F, Approx. 850 shots at 0°C / 32°F |
With
Live View shooting: |
Approx. 200 shots at 23°C /
73°F, Approx. 180 shots at 0°C / 32°F |
Dimensions
and Weight |
Dimensions
(W x H x D) |
Approx. 152.0 x 116.4
x 76.4mm / 6.0 x 4.6 x 3.0in. |
Weight |
Approx. 950g / 33.5oz.
(CIPA Guidelines), |
Approx.
860g / 30.3oz. (Body only) |
Operating
Environment |
Working
Temperature Range |
0°C - 40°C / 32°F -
104°F |
Working
Humidity |
85% or less |
Battery
Pack LP-E6 |
Type |
Rechargeable
lithium-ion battery |
Rated
Voltage |
7.2 V DC |
Battery
Capacity |
1800 mAh |
Dimensions
(W x H x D) |
Approx. 38.4 x 21.0 x
56.8mm / 1.5 x 0.8 x 2.2in. |
Weight |
Approx. 80g / 2.8oz. |
Battery
Charger LC-E6 |
Compatible
Battery |
Battery Pack LP-E6 |
Recharging
Time |
Approx. 2hrs. 30mins. |
Rated
Input |
100 - 240 V AC (50 /
60 Hz) |
Rated
Output |
8.4 V DC / 1.2 A |
Working
Temperature Range |
5°C - 40°C / 41°F -
104°F |
Working
Humidity |
85% or less |
Dimensions
(W x H x D) |
Approx. 69.0 x 33.0 x
93.0mm / 2.7 x 1.3 x 3.7in. |
Weight |
Approx. 130g / 4.6oz. |
Battery
Charger LC-E6E |
Compatible
Battery |
Battery Pack LP-E6 |
Power
cord length |
Approx. 1m / 3.3ft. |
Recharging
Time |
Approx. 2hrs. 30mins. |
Rated
Input |
100 - 240 V AC (50 /
60 Hz) |
Rated
Output |
8.4 V DC / 1.2 A |
Working
Temperature Range |
5°C - 40°C / 41°F -
104°F |
Working
Humidity |
85% or less |
Dimensions
(W x H x D) |
Approx. 69.0 x 33.0 x
93.0mm / 2.7 x 1.3 x 3.7in. |
Weight |
Approx. 125g / 4.4oz.
(excluding power cord) |
EF24-105mm
f/4L IS USM |
Angle
of View |
Diagonal extent: |
84° - 23°20' |
Horizontal
extent: |
74° - 19°20' |
Vertical
extent: |
53° - 13° |
Lens
Construction |
18 elements in 13
groups |
Minimum
Aperture |
f/22 |
Closest
Focusing Distance |
0.45m / 1.48ft. (from
image sensor plane) |
Max.
Magnification |
0.23x (at 105mm) |
Field of
View |
535 x 345 - 158 x
106mm / 21.1 x 13.6 - 6.2 x 4.2in. (at 0.45m) |
Stabilizer |
Lens shift type |
Filter
Size |
77mm |
Lens Cap |
E-77U |
Max.
Diameter x Length |
83.5 x 107mm / 3.3 x
4.2in. |
Weight |
Approx. 670g / 23.6oz. |
Hood |
EW-83H |
Case |
LP1219 |
